- Free Home delivery
- With protection circuit BMS
- 50km+ Range in Single charge
- Charge in 6hrs
- Detachable Hailong Case Battery
- Anti Theft Battery Pack with Keys Protection
- 1 Year Warranty
- Small in size than phosphet Battery
- 1000 ~ 1200 Life Cycle
Battery charger Link-
https://www.myinnovation.in/product-page/lithium-ion-ecycle-battery-charger
Visit Our Youtube Channel -
https://www.youtube.com/@sayaninsight
Visit Our Facebook Page -
https://www.facebook.com/sayan.creation
Hailong case battery packs are specially made battery. This are detachable battery pack,that's mean you can open the battery from you cycle and able to charge it from anywhere. You don.t need the cycle to carry with it. You get battery, base part, keys with this. The base part you need to attach in your cycle rod using welding/riveting/drilling etc. On the battery you get key lock system and charging socket system. This Battery is used in Electric cycle conversion kit with gear motors or hub motor both. This Battery fits for Both HUB Motor and DC gear Motor of 24volt rated only. You can connect 250watts/350watts motor easily with this battery. We manufacture this battery in own house and its made in INDIA product. Battery made with proper cells IR testing, Spot welding, Balancing and with Premimum quality BMS board, charge discharge testing and quality check. Its Higher in power, higher in Mileage than normal Lead acid Battery. Battery weight is also very light than lead acid battery. This battery is protected with over charge protection. Low discharge protection. This battery weight is very low than your normal lead acid battery. This Battery provides a lifespan of nearly 3 years where a normal lead acid battery sustain for only 1 year’s of life.
Use only lithium Ion charger for this battery. Do not use Lead acid Battery Charger.
Battery warranty –
1 Year warranty is available with this battery. Details of warranty policy is available at our “warranty Policy” Page.
Battery specification –
Battery Dimension
Length x Width x Height = Hailong Case
Weight = 4kg
Battery Wires -
We provide 2.5sqmm output wires from battery pack. For charging We socket in the battery Packs. We provide compatible male socket part also for easy to charging..
Battery cells Details -
Cell - Roofer 2500 mah 3C EV Grade
Casing Type - Hailong Case
Total no of cells used - 7x7=49pcs
Charge Cycle with full Capacity - 1200 aprox
BMS Specification - 7s20A, with Heat Sink protection
Maximum Battery Capacity - 18AH or 18,000 mah
Battery Energy – 432wh
Maximum Power Motor you can attach – 480 watts
Maximum discharge current - 20A
Maximum charging current - 10A
Battery standard voltage - 24v
Battery full charge voltage – 29.4v
Battery Low discharge voltage- 22.4v
Back up on 250 watts E cycle Motor -
On full charge 45-50Km aprox Back Up time of battery( tested with a 55 kg person)
Charging Specification -
Charger Voltage- 29v
Charger Current – 3amps max
24volt 18AH Hailong Case Electric Cycle Lithium Ion Battery Pack, 50km+ Mileage
Country Of Origin : India
